Material: SS304/316l; Galvanized Steel; Cold-rolled steel; Aluminum can be choosen
Surface: Brushed/Themosetting powder coating/Anodizing can be choosen treatment
Standard: Mounting Plate, Earth wire, Three-point lock, Door limiter
Protection: IP66,IK10
Color: Normal RAL7035 or RAL7032
Sizes as below
| # | Item Number | High (mm) | Width (mm) | Depth (mm) | Locks |
| 1 | EC01-1800x600x400 | 1800 | 600 | 400 | 1 |
| 2 | EE02-2000x800x500 | 2000 | 800 | 500 | 1 |
| 3 | EE03-2200x1000x600 | 2000 | 1000 | 600 | 1 |
● The main body frame specially made of nine-fold section by means of whole welding not only ensure high strength ofcabinet but aso reach IP66 waterproof level.
● Door limiter to prevent door closing unexpectedly when open
● Stainless steel bearing suspension loop can be installed on the top for easy movement.
● Vent plate with mesh, it can ventilate and dissipate heat while preventing foreign matter entering.
● Using a three-point locking, to lock the top and bottom of the door simultaneously for a more secure lock
